The story of the very first reverse gear in an American car

by Jonathan Roth | Dec 26, 2023

Making a car go backwards was not the most important part of the automobile’s development, but it sure is important in its operation. In fact, if the average automobile enthusiast was to guess which American-built car had the first reverse gear, he or she would likely say it was an early Ford model. In fact, that’s what I would have said if you asked me a few months ago. But then I had a random chat with my buddy Jack Ball, who shared with me a story about his great-grandfather, Frederic J. Ball, and the car he built more than a century ago: the Ball Tonneau Touring Car.

The Ball Tonneau Touring Car in The Horseless Age magazine, 1902. Source: Jack Ball.

Frederic J. Ball was born in Brooklyn, New York, in 1867. After graduating college, he became an apprentice machinist at the shop where his father was a partner, Ball and Jewell. Later, Ball and his father bought out the company and changed the name to G.M. Ball and Son. The company was completely controlled by Frederic Ball by 1898, at which point he changed its name to the New York Gear Works.

Frederic J. Ball. Source: Jack Ball.

In 1902, Frederic Ball invented what he called the “spur planetary reverse gear,” which had two forward speeds and a reverse gear. An avid seafarer, Ball originally sold these gears to be installed in boats. He then manufactured an automobile he named after himself, the Ball Tonneau Touring Car, with his spur planetary reverse transmission installed. He built six of these Ball cars as one-offs in his garage in Brooklyn, making them the first American-built cars with a reverse gear. On top of that, his gear was efficient and had a low cost of manufacture. Ball patented his reversing gear invention under patent number 671,747 on April 9, 1901, and began selling his cars (he also received subsequent patents in 1904 for the reversing mechanism under patent numbers 749,516 and 749,602).

He received a decent amount of attention for this in the emerging automotive community, even having an article written about his car in the December 17, 1902, issue of The Horseless Age magazine. (Yes, that is the actual name of the magazine. Obviously, car mags had much more whimsical names in the early 20th century.) As such, he soon caught the attention of Henry Ford and John Wanamaker. They approached him with an offer to purchase the rights to his spur planetary reverse gear, but he declined. Soon after this, Frederic’s shop was broken into, and his spur planetary reverse gear plans were stolen.

In 1903 the first Ford Model A cars (an early Model A that is different from the later ’27-’31 car that most people are familiar with) were sold in all Wanamaker stores, and Ball believed that they utilized the function of his mechanism in their transmissions, since it bore striking similarity to the reverse gear that he had designed and patented. After seeing the car, Ball began to surmise that the robbery in his workshop represented the theft of more than a simple set of drawings but instead the theft of his company’s future, and he sued Wanamaker for patent infringement. Unfortunately, Frederic was forced to drop his suit in 1905 due to a lack of funds. However, that same year, he signed two licensing agreements, one from Ford Motor Company and one from Buick Motor Company, allowing use of the spur planetary reverse gear he had devised. According to the agreements, both Ford and Buick were to pay Ball one dollar for every transmission manufactured by the companies containing Ball’s patented improvements.

Frederic J. Ball’s patent for his reversing gear.

Unfortunately, according to Jack, his great-grandfather never saw one dollar from either Ford or Buick. The problem was exacerbated after the Ford Motor Company won the infamous Selden patent case. George B. Selden was a patent lawyer and inventor who received a patent for an automobile in 1895. He sold William C. Whitney the rights to his patent in 1899. Then Whitney and Selden collaborated to recoup royalties from other nascent automakers. For a time, they were successful. Eventually, however, Henry Ford and four other car manufacturers contested the patent infringement suit filed by Selden and Whitney.

Their legal protestations were not surprising, as every automaker had to pay a royalty to Selden and Whitney simply because they effectively patented the concept of an automobile. Initially, the court ruled in favor of Selden. However, on appeal, Ford won in 1911 and no longer had to pay royalties to Selden. Ford used his victory in this case to justify not paying the patent rights to other inventors, like Frederic J. Ball.

New York Gear Works agreement with the Ford Motor Company, 1905. Source: Jack Ball.

Frederic did not pursue any further action against Ford or Buick, at least that Jack is aware of. This is perhaps because Frederic realized that he did not have the resources for a legal case against two large automotive corporations and recognized that Ford was emboldened by his win in the Selden patent case. Jack does have a letter that Frederic wrote to Henry Ford II later in the early 1950s, where he attempted to receive recompense. In this letter that appears to be a “Hail Mary,” Frederic’s desperation in trying to collect from Ford is clear. After relaying the history of his invention, patent, and lawsuit against the elder Ford, he states, “I have been a good loser for nearly 50 years. The use of this transmission, because of its low cost of manufacture and efficiency, had a great deal to do with the success of the Ford Motor Co. I think it would be fair and proper to give me some remuneration. Do you not agree that there is a moral obligation? I invented the transmission and Henry Ford never paid me for its use. I have been informed that during the life of these patents the Ford Co. made three million cars. Hoping you will consider this matter in a favorable light.”

New York Gear Works ad in The Horseless Age magazine, 1902. Source: Jack Ball.

The Ball Tonneau Touring Car. Source: Jack Ball.

Unfortunately, this letter did not garner a response, and Frederic J. Ball died January 18, 1958, in Paterson, NJ, having never seen a dollar from Ford or Buick. And the six Ball cars that were built? Jack is not aware of the whereabouts of any of them, or if any even survived. He was contacted at one point by someone who claimed to have the transmission from one of the cars, but the lead vanished as quickly as it arrived.

Obviously, as this story shows, there was much to be hammered out in terms of automobile patents in the early days of the car. Those patent issues have existed in some form through the automobile history. In fact, on this very site, we discussed the struggles of Robert Kearns, who patented an intermittent windshield wiper 45 years ago. Kearns’ story was even made into a major motion picture, “Flash of Genius,” which serves to emphasize the drama that occurs and the alleged dishonesty and shady backroom dealings that are suspected in pursuit of keeping the unstoppable march of technology moving forward. Perhaps someday Frederic will receive similar recognition for his groundbreaking invention. Maybe this article will even help in that endeavor! In the meantime, the only thing Jack has from his grandfather today is ironically the only thing Frederic ever got from his pioneering invention—the pride in it.
